SolidFace Drawing Multi-user License

SolidFace Drawing Multi-user License

$99.00 per simultaneous user + taxes

SolidFace Drawing multi-user license for Microsoft Windows. Choose from P01 to P25 simultaneous users; each purchase delivers one license key for the selected user count.

SKU: P978 Category:

Description

SolidFace Drawing Multi-user License

SolidFace Drawing allows you to create, simulate and detail projects in a practical and agile way. It has an associative and parametric structure that supports the entire project process through detailing.

System Requirements

  • 1 GHz or higher 32-bit (x86) or 64-bit (x64) processor
  • 1 GB RAM (32-bit) or 2 GB RAM (64-bit)
  • 1 GB of available disk space
  • 256 MB or higher off-board graphics device
  • Minimum resolution of 1024×768

Compatibility

  • Windows XP/7/8/10/11 operating systems
  • Clipboard communication with other Windows applications
  • CAD communication through XT, IGES, DWG and DXF standards

Features

  • Direct correction of commands
  • Associative dimensioning, strong and easy to use
  • Geometric operations through entity selection
  • Easy references for geometric constructions such as midpoint, arc center, circle center and extreme point
  • Polygonal curves (splines) for complex geometries such as cams and gears
  • Measurements in millimeters, feet or inches according to user configuration

General

  • Configurable toolbars
  • Multiple projects open simultaneously
  • Graphic screen division into up to four views
  • Printing with Print Preview

Integrated Modules

  • Drawing module with permission to add 3D models
  • 2D collision testing
  • Motion Simulation for testing the 2D dynamic behavior of mechanisms

Parameterization

  • Parametric construction without external programming languages or complex dimensional restrictions
  • Associative hatching and filling, automatically adapting to contour changes
  • Parametric formats in A0, A1, A2, A3, A4 or customized formats
  • Parameterized texts with variables or tables for automatic filling of shapes, symbol labels and parts list attributes
  • Parametric bill of materials and associative link with Excel and Access
  • Creation of 3D and 2D part families using CSV or TXT tables
  • Local and global variables
  • Parametric variables via command, question or table
  • Creation of part families
  • If-then-Else logical conditions

For more information, visit solidface.com
